Marka:HPE
Anahtar tipi:Yönetilmeyen
Anahtar katmanı:L2
Servis kalitesi (QoS) desteği:Evet
Temel açma kapama RJ-45 Ethernet giriş sayısı:24
Temel açma kapama RJ-45 Ethernet giriş türü:Gigabit Ethernet (10/100/1000)
Kurulu SFP modül sayısı:0
Kurulu SFP+ modül sayısı:0
SFP+ modülü yuva sayısı:2
Ağ standartı:IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
10G desteği:Evet
Tam iki taraflı baskı:Evet
Akış kontrol desteği:Evet
Auto MDI/MDI-X:Evet
Adres tablosu boyutu:16384 Kayıt
Yönlendirme/geçiş kapasitesi:88 Gbit/s
İşlem hacmi:65,5 Mpps
Gecikme (10-100 Mbps):8 µs
Gecikme (1 Gbps):16 µs
Gecikme (10 Gbps):2 µs
Paket ara belleği:1,5 MB
Raf montajı:Evet
İstiflenebilir:Evet
Form faktörü:1U
Ürün rengi:Gri
Flash bellek:8 MB
Güç kaynağı dahil:Evet
AC girdi voltajı:100 - 240 V
AC girdi frekansı:50 - 60 Hz
Güç tüketimi:21 W
Ethernet üzerinden güç desteği (PoE):Hayır
Çalışma ısısı aralığı:0 - 40 °C
Depolama sıcaklığı aralığı (Celsius):-40 - 70 °C
Çalıştırma nem aralığı:5 - 95%
Çalışmama nemi:5 - 95%
Genişlik:440 mm
Derinlik:238 mm
Yükseklik:44 mm
Ağırlık:2,9 kg
Uyumlu Sistem (HS) kodu:85176990
Açıklama:The HP 1420 Switch Series consists of unmanaged Gigabit Ethernet switches, for small businesses and others looking for plug-and-play basic Layer 2 connectivity for their network, including low-cost PoE+ and 10-Gigabit uplink models.

The HP 1420 Switch Series has four models: 16-port 10/100/1000; 24-port 10/100/1000 with two SFP Gigabit ports; 24-port 10/100/1000 ports of which 12 are PoE+ enabled (124W PoE budget); and 24-port 10/100/1000 with two SFP+ 10-Gigabit ports. All are fanless. They come with a limited lifetime warranty and 24X7 phone support for the first three years of ownership.
